The FT232RL module is a small USB to TTL converter and used with different Arduino boards. The TTL is used to program Arduino boards. This has Six pins where the pins are used to communicate with other microcontrollers. The TTL converter has Data transfer rates from 300 baud to 3 Mbaud (RS422, RS485, RS232) at TTL levels.



FT232RL Module Specifications:

• Support 3.3V, 5V
• Main Color: Red
• Chipset: FT232RL
• USB power has over current protection, using 500MA self-restore fuse
• RXD/TXD transceiver communication indicator
• Module Size: About 36mm(length)*17.5mm(width)
• Pitch:2.54mm
• Pin definition: DTR,RXD,TX,VCC,CTS,GND
• Interface : Mini USB



Package Includes:

1 x FT232RL USB to TTL 3.3V/5V FTDI Serial Adapter Module
